Specs
Sizing
Geometry
Frameset

Frame Alpha Gold Aluminium, rack & mudguard mounts, internal routing, kickstand mount, 135x5 mm QR
Fork SR Suntour NEX, coil spring, preload, 50 mm travel, 100x5 mm QR

Wheels

Hub front Shimano
Hub rear Shimano
Rim Alex Rims DP23, alloy, 36-hole, Presta valve
Spokes Stainless steel black
Tyre Schwalbe Energizer Active Plus, Puncture Guard, Twin Skin (50-622)
Max tyre size 700x50c with or without fenders

Drivetrain

Shifter Shimano Acera M3000, 9 speed
Rear derailleur Shimano Altus M2000, long cage
Crank ProWheel alloy, 170 mm
Chainring ProWheel 38T narrow/wide steel, w/alloy guard
Cassette Shimano HG200, 11-36, 9 speed
Chain KMC E9S, 9-speed
Pedal VP-857

Components

Saddle Bontrager Boulevard
Seatpost Alloy, suspension, 31.6 mm, 300 mm length
Handlebar Bontrager aluminium touring
Grips Bontrager Satellite Plus
*Stem Size: XS, S, M
Bontrager alloy quill, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length
Size: L
Bontrager alloy quill, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Head set VP sealed cartridge, 1-1/8", threaded
Brake Shimano MT200 hydraulic disc
Brake rotor Shimano RT10, CenterLock, 160 mm

Accessories

Charger Bosch standard 4A, 220–240V
Motor Bosch Performance Line Cruise, 250 watt, 65 Nm, 20 mph (25 km/h in Europe)
*Light Size: XS, S, M, L
AXA Blueline taillight
Size: XS, S, M, L
Herrmans H-Black MR4-E, 40 Lux/120 lumen
Computer Bosch Intuvia
Kickstand Pletscher Comp Flex 18
Cargo rack MIK Compatible alloy rear rack
Mudguard SKS plastic

Weight

Weight M - 23.58 kg / 51.99 lbs (excluding battery)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice. Prices shown are manufacturer's suggested retail prices.

Weights are based off pre-production products at time of publication. Weights may vary in final production.

Size

XS

S

M

L

Rider Height

147 - 155 cm

4'10" - 5'1"

155 - 165 cm

5'1" - 5'5"

165 - 175 cm

5'5" - 5'9"

175 - 186 cm

5'9" - 6'1"

Inseam

69 - 73 cm

27" - 29"

72 - 78 cm

28" - 31"

77 - 83 cm

30" - 33"

82 - 88 cm

32" - 35"

Sizing table
Frame size letter A — Seat tube B — Seat tube angle C — Head tube length D — Head angle E — Effective top tube F — Bottom bracket height G — Bottom bracket drop H — Chainstay length I — Offset J — Trail K — Wheelbase L — Standover M — Frame reach N — Frame stack
XS 39.0 71.0° 16.0 68.5° 58.2 30.2 4.5 47.7 4.5 8.2 111.5 42.1 38.5 57.1
S 44.0 70.0° 16.0 68.5° 58.8 28.6 6.2 50.2 4.5 9.5 114.1 44.0 37.6 61.6
M 50.0 70.0° 18.0 68.5° 60.9 30.2 6.2 50.2 4.5 9.5 115.0 44.0 37.8 63.5
L 55.0 70.0° 18.0 68.5° 62.4 30.2 6.2 50.2 4.5 9.5 116.5 44.0 39.3 63.5
